Duplex 2205 / 2507 Fittings and Flanges Supplier in China: HuaboPipe

Looking for a China supplier of duplex 2205 and 2507 butt weld fittings and flanges? Huabo Pipe Industry Co., Ltd. (brand HuaboPipe) keeps 2205 and 2507 as stocked grades. Fittings are cold press formed; flanges are forged. Standard sizes DN15 to DN1200; larger sizes are made to drawing, up to DN3000. EN 10204 3.1 material test reports (MTRs) are available, with PMI available. Regular sizes are held in stock; non standard lead time depends on quantity. Founded 2004; company in Wenzhou; factory in Lishui, Zhejiang.

Facts at a glance

What we supply in duplex

• Butt weld fittings: 90°, 45° and 180° elbows, equal and reducing tees, crosses, concentric and eccentric reducers, caps, stub ends. Standard sizes DN15 to DN1200; larger sizes are made to drawing, up to DN3000.
• Forged flanges: welding neck (WN), slip on (SO), long welding neck (LWN), blind, lap joint. Non standard to drawing.
• Same project list can mix 304/304L, 316/316L, 310S, 321 with 2205 and 2507.

Duplex is often chosen where strength and chloride resistance matter more than 316L. Final grade follows the project design. For a side by side of 316L and 2205, see 316L vs duplex 2205 fittings. Product pages: duplex pipe fittings, duplex flanges, butt weld fittings, forged flanges.

Quality and certificates

Heat numbers are checked on incoming material and kept traceable on finished parts. PMI is available. Corrosion tests can be arranged to customer requirements. EN 10204 3.1 MTRs are available. EN 10204 3.2 is also available on request. PT, UT, RT and hydrostatic tests follow the order. Heat treatment: solution annealing. Surface treatment: polishing, pickling, sand blasting and sand tumbling.

• Special equipment production license (pressure piping components)
• ISO 9001, ISO 14001, ISO 45001
• Certificate of Quality Assurance System (PED 2014/68/EU Annex I 4.3 & AD 2000-Merkblatt W 0), issued by TÜV SÜD
• DNV and BV manufacturer approvals
• National High Tech Enterprise; Zhejiang specialized and innovative SME

Certificate scans: Certificates. PT overview: penetrant testing guide.

Stock and lead time

2205 and 2507 are stocked grades. Regular sizes are held at the Wenzhou Longwan stock point. Non standard and large diameter parts are scheduled at the Lishui factory; lead time and MOQ are confirmed after we review the list.

How to inquire

Send grade (2205 or 2507, or the UNS number), product name, size, wall or pressure class, standard, quantity, and the tests or certificates you need. Email lucas@hbpipe.com or use the Contact form.

FAQ

Does HuaboPipe make duplex 2205 butt weld fittings?

Yes. 2205 is a stocked grade. Elbows, tees, reducers, caps and related butt weld fittings are cold press formed. Standard sizes DN15 to DN1200; larger sizes are made to drawing, up to DN3000.

Are 2507 flanges forged?

Yes. All HuaboPipe duplex flanges are forged. 2507 flange material corresponds to ASTM A182 F53.

Can you issue material certificates for duplex?

Yes. EN 10204 3.1 MTRs are available. PMI is available. Corrosion tests can be done to customer requirements. EN 10204 3.2 is also available on request.

How do I choose between 2205 and 2507?

2507 has higher alloy content and is often used in higher chloride or more aggressive service. Final choice follows medium, concentration, temperature and design pressure. If the design already names a grade, buy to that grade.

Can duplex and 316L ship on one order?

Yes. 304/304L, 316/316L, 310S, 321, 2205 and 2507 are all stocked grades and can be quoted on one list.

How do I get a quote?

Email lucas@hbpipe.com with grade, product, size, wall, quantity and test needs.
